High durability servos designed for the most demanding applications.

– Dimensions – 48.0 x 21.0 x 51.5mm or 1.89 x 0.83 x 2.03in

– Weight – 130 g or 4.6 oz

– Max Torque at 7.4V – 48 kgf * cm or 667 oz * in

– Speed at 7.4V – 0.07 sec/60°

Cad File Download

High durability servos designed for the most demanding applications.

– Dimensions – 48.0x 21.0 x 51.0mm or 1.89 x 0.83 x 2.01 in

– Weight – 127g or 4.48 oz

– Max Torque at 7.4V – 48.0 kgf * cm or 667 ozf * in

– Speed at 7.4V – 0.07 sec/60°

Cad File Download

High durability servos designed for the most demanding applications.

– Dimensions – 48.0x 21.0 x 51.5mm or 1.89 x 0.83 x 2.03 in

– Weight – 130g or 4.59 oz

– Max Torque at 12.0V – 50.0 kgf * cm or 694 ozf * in

– Speed at 12.0V – 0.09 sec/60°

Cad File Download

High durability servos designed for the most demanding applications.

– Dimensions – 48.0x 21.0 x 51.0mm or 1.89 x 0.83 x 2.01 in

– Weight – 127g or 4.48 oz

– Max Torque at 12.0V – 50.0 kgf * cm or 694 ozf * in

– Speed at 12.0V – 0.09 sec/60°

Cad File Download

High durability servos designed for the most demanding applications.

– Dimensions – 48.0x 21.0 x 51.5mm or 1.89 x 0.83 x 2.03 in

– Weight – 130g or 4.59 oz

– Max Torque at 28.0V – 46.0 kgf * cm or 639 ozf * in

– Speed at 28.0V – 0.07 sec/60°

Cad File Download

High durability servos designed for the most demanding applications.

– Dimensions – 48.0x 21.0 x 51.0mm or 1.89 x 0.83 x 2.02 in

– Weight – 127g or 4.48 oz

– Max Torque at 28.0V – 46.0 kgf * cm or 639 ozf * in

– Speed at 28.0V – 0.07 sec/60°

Cad File Download

High durability servos designed for the most demanding applications.

– Dimensions – 48.0x 21.0 x 51.0mm or 1.89 x 0.83 x 2.02 in

– Weight – 127g or 4.48 oz

– Max Torque at 28.0V – 46.0 kgf * cm or 639 ozf * in

– Speed at 28.0V – 0.07 sec/60°

Cad File Download

High durability servos designed for the most demanding applications.

– Dimensions – 30.3 x 15.0 x 31.4mm or 1.19 x 0.59 x 1.24in

– Weight – 44 g or 1.55 oz

– Max Torque at 7.4V – 10.3 kgf * cm or 143 oz * in

– Speed at 7.4V – 0.14 sec/60°

Cad File Download

High durability servos designed for the most demanding applications.

– Dimensions – 39.4 x 15.0 x 29.4mm or 1.55 x 0.59 x 1.16 in

– Weight – 44 g or 1.55 oz

– Max Torque at 12.0V – 9.6 kgf * cm or 115.3 oz * in

– Speed at 12.0V – 0.16 sec/60°

Cad File Download

High durability servos designed for the most demanding applications.

– Dimensions – 39.4 x 15.0 x 29.4mm or 1.55 x 0.59 x 1.16 in

– Weight – 45 g or 1.59 oz

– Max Torque at 12.0V – 9.6 kgf * cm or 115.3 oz * in

– Speed at 12.0V – 0.17 sec/60°

Cad File Download
